LS10 – LS 20

Intended Use of the Equipment

A switch box is a device used for on the pneumatics rotary actuators for showing the position of the valve visually and giving output signal according to the position of the valve. An ex proof switch box used on the potentially explosive and hazardous areas.

Technical Specification

  • On-Off position indicator
  • Compact body
  • Ex-proof, Ex d IIC T6, Ex ia IIC T6 (On order)
  • IP67
  • Electrostatic dyed aluminium injection body
  • 2 pieces cable input NPT 1/2", M20 (On order)
  • Easy mounting with namur standard, stainless steel bracket
  • Used mechanic switch as standard. On order, can be used promixity switch.
  • Working temperature: -20 °C ile +80 °C
